500v Rack Mount Firfircoonaanta firfircoon
Raadinta shaandhaynta 500V ee lagu kalsoonaan karo Guusa waxay siisaa xalal tayo sare leh qiimaha jumlada, loogu talagalay in lagu buuxiyo shuruudaha warshadaha degdegga ah. Xirayaashu waxay hubiyaan waxqabadka ugu habboon iyo hufnaanta. Nala soo xiriir hadda si aad u hesho macluumaad dheeraad ah oo aad si toos ah heshiis toos ah uga hesho warshadeena!
Filter-ka-shaandhaynta la-lihi ee 500v Rack Mount Qaybtan xaraashka ah waxay u shaqaysaa kontoroolka dhijitaalka ee Advant + CPLD CPLD CPLD iyo topology sedex heer sare ah oo loogu talagalay magdhowga saxda ah ee loo yaqaan 'hadda loo gudbiyo magdhowga 50-aad. Naqshaddeeda modular waxay fududeysaa nabaad-guurka iyada oo loo marayo isku xirnaan isbarbar dhiga, karti u yeelo awood sare inta uu fududeeyo dayactirka. Moodeelka 100A ee lagu qiimeeyay ayaa si wax ku ool ah wax uga qabashada dhalanrog iswaafajinta codsiyada korantada. Qaboojinta hawada ee khasabka ah waxay xaqiijineysaa hawlgal la isku halleyn karo, muddo dheer. Qandaraaska loo yaqaan '500v' oo ah shaandhada is-waafajinta ee loo yaqaan 'Brack'
Tilmaanta Moodeelka:
| Good | Luus | 0.5 | 100a | / | 4l | R |
| Koodh ganacsi | Filterka firfircoon | Heerka korantada 0.5: 500v ± 20% |
Awoodda la qiimeeyay (KVar) 100A | 3l: saddex-weji saddex-silig 4L: Saddex-weji-silig |
R: Rack Mount |
Tilmaamaha:
● U adeegso DSP + CPLD Core RPLD Core Core, oo ah tikniyoolajiyada sare ee topology, oo ah tikniyoolajiyad is-ogaalnimo ee is-ogaalka ah iyo istiraatiijiyadda xakamaynta ee PWM si loo gaaro magdhow sax ah ee is-waafajinta.
● Qaadashada naqshad heer-gabood leh, kaas oo fududeeya isku xirnaanta isbarbar dhiga ee cutubyo badan, waxay qaadataa meel yar oo waa fududahay in la ilaaliyo.
Dejinta qaab dhismeedka qaab dhismeedka hawada madax-bannaan iyo bakhaarada madaxa banaan waxay hubisaa howlgalka xasilloon ee qalabka.
● Waxay sifeyn kartaa is-afgaranthicis badan oo iswaafajin ah, laga bilaabo 2 illaa 50 iswaafajin, iyo xallinta dhibaatada saddex-waji isku-dheellitirnaan isku mid ah.
● Heerka miisaanka shaandhaynta is-beddelka ayaa sarreeya. Haddii awooddu oggol tahay, heerka shaandhaynta shaandhaynta hadda la is-beddelo wuxuu noqon karaa mid ka sarreeya 95%. Samee 100% wax soo saarka xaddidaadda hadda si loo hubiyo hawlgal muddada fog ah ee qalabka.
Codsiyada:
500V Rack Rontans-ka Brack Firfircoonaanta firfircoon ayaa muhiim u ah dayactirka tayada awoodda iyo isku halaynta qalabka ee codsiyada korantada ee kala duwan:
● Warshadaha culus:Qiyaasta yaraanta ee ay soo saartay matoorro waaweyn, VFDs, iyo waxyaabo kale oo aan toos ahayn oo aan toos ahayn oo lagu dalbanayo goobaha warshadaha.
● Nidaamyada tamarta dib loo cusbooneysiin karo:Dejinta wax soo saarka korantada ee ka socota beeraha qorraxda iyo dabaysha ee ku xidhan girt-kotat-ka sare.
● Saliid iyo gaas:Hubinta hawlgalka la isku halleyn karo ee qalabka muhiimka ah ee nidaamyada qaybinta korantada korantada korantada.
● Hawlgallada Macdanta:Ilaalinta qalabka elektiroonigga ah ee xasaasiga ah iyo joogtaynta tayada awoodda ee deegaannada adag.
500V Rack Rontals-ka Brack Firfircoonaanta Firfircoon ee Brack waxay bixiyaan yareynta is waafajinta ee nidaamyada korantada ee korantada, hubinta xasilloonida iyo isku halaynta.
Cayayaanka farsamada:
| 220V taxanaha | 380v taxanaha | 500V taxanaha | 690V taxanaha | ||
| Sare | <2000m, oo ka sarreysa 2000m, oo dhalleeceeyso GB / T38599.2 | ||||
| Heerkulka deegaanka | -20 ~ + 50 ℃ | ||||
| Qoyaan qaraabo ah | ≤90%, majiraan uumi-baxa dusha marka heerkulka ugu yar ee ugu hooseeya uu yahay 25 ℃ | ||||
| Heerka wasakhda | Heerka III hoosta | ||||
| Ku shaqeynta korantada | AC220V ± 20% | AC380V ± 20% | AC500V ± 20% | Ac690v ± 20% | |
| Shaqo soo noqnoqoshada | 50hz ± 5% | ||||
| Magdhow hadda | 25a | 25/50/75/100 / 150a | 100a | 100a | |
| Qaab dhismeedka Grid | L / n | 3p3w / 3p4w | 3p3w / 3p4w | 3p3w / 3p4w | |
| Tirada cutubyada ku xidhan isbarbar dhig |
Dibligshenay | ||||
| Guud ahaan waxtarka mashiinka | ≥97% | ||||
| Qaab dhismeedka Grid | 32khz | 16khz | 12.8khz | 12.8khz | |
| Baaxadda magdhowga | 2 ~ 50 jeer, heerka magdhow hal magdhow ayaa la hagaajin karaa | ||||
| Xulashada Shaqada | Awoodda falcelinta | Awoodda falcelinta, awoodda falcelinta + asymmetry | |||
| Awoodda falcelinta Heerka Magdhowga |
≥95% | > 92% | |||
| Shaandhaynta dhexdhexaadnimada awood |
Awoodda shaandhaynta xariiqda dhexdhexaad ah waa 3 jeer oo ah awoodda shaandhaynta wejiga | ||||
| Waqtiga jawaabta oo buuxda | <10ms | 40ms | 40ms | 40ms | |
| Buuq | ≤60db | ≤60db | ≤65db | ≤65db | |
| Habka Xakamaynta | 2-wado Rs485 Interface (taageerayaasha GPRS / WiFi) | ||||
| Ilaalinta | Xad dhaaf, softiweer / Qalabka isku-dhafka ah, xad-dhaafka girvolcoltage iyo hoos udhac, koronto-daran, korantada, xad-dhaafka ah, difaac aan caadi ahayn, iwm. | Culeys, softiweer / qalabka korka, xad-dhaafka wadnaha, grigolvoltige, isbarbardhiga korantada, korodhka korantada, xad-dhaafka korantada, si aan caadi ahayn, difaac wareejinta wareega, iwm. | |||
| Habka rakibaadda | Rack / gidaarka | Xaraf | |||
| Khadka soo socda | Dib u soo gala (nooca rux), soo gala sare (gidaarka darbiga) | Xariiqda soo gala | |||
| Heerka Ilaalinta | Ip20 | ||||
Moodeel & faahfaahin:
| Moodhyada | ||||
|---|---|---|---|---|
| Nambarka moodalka | Lagu qiimeeyay hadda (a) | Nidaamka Nidaamka (v) | Cabbir (d * w * h) | Habka qaboojinta |
| Gy apf-0.22-25a / 2l-r / w / w / w / w | 25 | 220 | 220 * 330 * 160mm | Qaboojinta khasabka ah |
| Gy apf-0.4-25a / 4l-r / w / w / w | 25 | 380 ± 20% | 460 * 490 * 89mm | |
| Gy apf-0.4-50aa / 4l-r / w / w / w | 50 | 380 ± 20% | 460 * 490 * 89mm | |
| Gy apf-0.4-75a / 4l-r / w / w / w / w | 75 | 380 ± 20% | 500 * 510 * 190mm | |
| Gy apf-0.4-100a / 4l-r / w / w / w / w / w | 100 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy apf-0.4-150a / 4l-r / w / w | 150 | 380 ± 20% | 500 * 550 * 240mm | |
| Gy apf-0.5-100a / 4l-r / w / w / w / w | 100 | 500 ± 20% | 495 * 675 * 275mm | |
| Gy apf-0.69-100a / 4l-r / w / w | 100 | 690 ± 20% | 495 * 675 * 275mm | |
